Automatical Valley Flashing Tile Roll Forming Machine With PANASONIC PLC Control System

Name: Automatical Valley Flashing Tile Roll Forming Machine With PANASONIC PLC Control System
Brand: TECHWELL
Price: 1 USD

Best Automatical Valley Flashing Tile Roll Forming Machine With PANASONIC PLC Control System wholesale

Place of Origin : China

Brand Name : TECHWELL

Certification : CE

Model Number : TW-RCM

MOQ : 1 Set

Price : Contact Us

Packaging Details : Standard packing

Delivery Time : 55-65 working days

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Material thickness : 0.3-0.7mm

Weight Capacity Of Decoiler : 5 Ton

Forming Station : approx 20 ( depend on profile drawing )

Axis Diameter : ¢ 75mm

Working Speed : 0-15 m/min

Type of Cutting : Hydraulic cutting

Contact Now

Automatical Valley Flashing Tile Roll Forming Machine for Making Roof Ridge

A). Applications of Ridge Valley Roll Forming Machine

Roof ridge cap, ridge cap, ridge tile; ridge valley; ridge flashing; valley flashing; top hat cap, top ridge cap.

B). Main Specifications of Ridge Valley Roll Forming Machine

Material thickness: 0.3-0.7mm
Material width: depend on customer’s requirement
Decoiler Type: manual or automatical type ( depend on customer’s requirement )
Weight Capacity Of Decoiler: 5 Ton
Main Motor Power: 5.5 Kw
Hydraulic Motor Power: 7.5 Kw
Forming Station: approx 20 ( depend on profile drawing )
Axis Diameter: ¢ 75mm
Working Speed: 0-15 m/min
Transporting Type: Chain Transmission
Heat Treatment of Cutting Blade: HRC 50-60
Type of Cutting: Hydraulic cutting
Electrical Control: PLC Frequency Control System with touch screen
PLC: PANASONIC Brand
Encoder: OMRON Brand
Transducer: PANASONIC Brand
Machine Weight: about 5 Ton

C).Working Flow of Ridge Valley Roll Forming Machine

Decoiler --- Fedding Guide --- Roll Forming --- Pressing --- Cut-to-length --- Run out table

D). Main Components of Ridge Valley Roll Forming Machine

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
Main Roll Forming Machine	1 Unit
Hydraulic Pressing Device	1 Unit
Hydraulic Cutting Device	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control	1 Unit
Output table	1 Unit

E). Reference Drawings of Ridge Valley

Automatical Valley Flashing Tile Roll Forming Machine With PANASONIC PLC Control System

F). Our Adavntages of Machine Manufacturing

Top Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

G). More Machine Pictures of Roll Forming Machines

Automatical Valley Flashing Tile Roll Forming Machine With PANASONIC PLC Control System

H). FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available.

Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine.

Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.

Q: What size decoiler can you supply us with?
A: From 5-ton decoiler to a 25-ton motorised hydraulic decoiler.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.

Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.
